LILYGO ESP32 OLED V3.0
ESP32 development board with integrated 0.96-inch SSD1306 OLED display, 4MB Flash, 520KB SRAM, WiFi, Bluetooth dual-mode, USB-C, and onboard LiPo battery charging for compact IoT display projects.
$8.16
Tap any value to browse matching devices
Specifications
Components
Dual-core Xtensa LX6 at 240MHz with 520KB SRAM, WiFi, and Bluetooth dual-mode.
0.96-inch monochrome OLED display at 128×64 resolution via I2C interface.
Onboard single-cell LiPo battery charger with JST connector.
Bus Interfaces
Overview
The LILYGO ESP32 OLED V3.0 is a compact all-in-one development board combining the ESP32 Tensilica dual-core processor (240MHz) with an integrated 0.96-inch SSD1306 OLED display. It offers 4MB of Flash storage and 520KB SRAM, along with WiFi 802.11 b/g/n and Bluetooth dual-mode (Classic + BLE) connectivity. The board features USB-C for power and programming, and includes onboard lithium battery charging circuitry with a JST connector for LiPo batteries. It is ideal for small IoT display nodes, wireless sensor displays, portable environmental monitors, and smart home status panels where a built-in screen is needed without external wiring.
Use Cases
4IoT
Internet of Things applications including connected sensors, actuators, and smart devices that communicate over WiFi, BLE, LoRa, or other wireless protocols.
Environmental Monitoring
Monitoring environmental conditions like temperature, humidity, air quality, and weather data using remote sensors.
Smart Home
Home automation devices for controlling lighting, climate, security, and appliances.
Weather Display
A dedicated screen that shows weather information including current conditions, temperature, humidity, pressure, and multi-day forecasts.
