# LILYGO T4 S3

> LILYGO T4 S3 is an ESP32-S3 development board with a 2.41-inch AMOLED touchscreen (450x600), 16MB flash, 8MB PSRAM, microSD slot, Wi-Fi, and Bluetooth 5 LE.

## Quick Facts

- **Brand:** LILYGO
- **Board Type:** ESP32-S3
- **Price:** ~$56.89
- **Product Readiness:** developer
- **CPU:** ESP32-S3R8
- **CPU Architecture:** Xtensa LX7 32-bit
- **CPU Cores:** 2
- **RAM:** 512KB SRAM
- **PSRAM:** 8MB
- **Flash:** 16MB
- **USB:** USB-C
- **Power:** 5V
- **Operating Voltage:** 3.3V
- **Antenna:** Built-in PCB antenna
- **SD Card:** microSD
- **Display:** 2.41" AMOLED 450x600

## Connectivity

- **Wifi:** 802.11 b/g/n
- **Bluetooth:** BLE 5.0

## Open Source

- **Firmware:** Yes
- **Schematics:** No
- **PCB Layout:** No

## Compatible Firmware

arduino, platformio, micropython, esphome

## Use Cases

- iot
- smart-home-dashboard
- smart-home
- digital-signage
- media-player

## Components

- **ESP32-S3R8** (mcu): Dual-core Xtensa LX7 at 240MHz with Wi-Fi 802.11 b/g/n, Bluetooth 5.0 LE, USB OTG, 16MB flash, 8MB PSRAM. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.espressif.com%2Fsites%2Fdefault%2Ffiles%2Fdocumentation%2Fesp32-s3_datasheet_en.pdf&ref=openhardware.directory&product=lilygo-t4-s3&source=md-export)
- **2.41" AMOLED** (display): 2.41-inch SPI RGB AMOLED display with 450x600 resolution, 800 cd/m² brightness, QSPI interface, and active area 36.2x48.96mm. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Flilygo.cc%2Fproducts%2Ft4-s3&ref=openhardware.directory&product=lilygo-t4-s3&source=md-export)

## Protocols

- **SPI**
- **QSPI**
- **I2C**
- **UART**
- **PWM**
- **ADC**
- **USB OTG**

## Available Software

- **[Arduino IDE]()** (open-source)
- **[PlatformIO]()** (open-source)
- **[MicroPython]()** (open-source)

## Description

## Overview

The LILYGO T4 S3 is a premium ESP32-S3-based development board featuring a vibrant 2.41-inch SPI RGB AMOLED touchscreen with 450×600 pixel resolution at 800 cd/m² brightness, driven via QSPI interface. Powered by the ESP32-S3R8 dual-core Xtensa LX7 processor at 240MHz, it offers 16MB flash and 8MB PSRAM for demanding applications. The board includes a microSD card slot, boot and reset buttons, and supports 2.4 GHz Wi-Fi and Bluetooth 5 (LE). Multiple form factors are available including soldered/unsoldered headers and a shell version. Development is supported via Arduino IDE, PlatformIO, and MicroPython using C, C++, or Lua. Available in regional warehouse variants (China, Germany, USA) for faster shipping.

## Where to Buy

- [LILYGO Official](https://openhardware.directory/r?to=https%3A%2F%2Flilygo.cc%2Fproducts%2Ft4-s3&ref=openhardware.directory&product=lilygo-t4-s3&source=md-export) — $56.89

## Resources

- [product](https://openhardware.directory/r?to=https%3A%2F%2Flilygo.cc%2Fproducts%2Ft4-s3&ref=openhardware.directory&product=lilygo-t4-s3&source=md-export)
- [github](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2FXinyuan-LilyGO&ref=openhardware.directory&product=lilygo-t4-s3&source=md-export)

## Tags

`esp32-s3`, `amoled`, `touchscreen`, `wifi`, `bluetooth`, `psram`, `lilygo`, `iot`, `display`
