# M5Stack FIRE V2.7

> Feature-rich ESP32 IoT dev kit with 2.0" IPS display, 8MB PSRAM, 16MB flash, MPU6886 IMU, BMM150 magnetometer, 10x SK6812 RGB LEDs, microphone, speaker, microSD, 500mAh battery, and M5GO charging base.

## Quick Facts

- **Brand:** M5Stack
- **Board Type:** dev-board
- **Price:** ~$49.9
- **Product Readiness:** developer
- **CPU:** Xtensa LX6 dual-core @ 240MHz, FPU, hardware crypto (AES/SHA/RSA)
- **CPU Architecture:** Xtensa LX6
- **CPU Cores:** 2
- **RAM:** 520KB SRAM
- **PSRAM:** 8MB
- **Flash:** 16MB
- **USB:** USB-C
- **Power:** 5V
- **Operating Voltage:** 3.3V
- **Dimensions:** 54 x 54 x 30.5mm
- **Weight:** 62.3g
- **Battery:** 500mAh
- **Charging Port:** USB-C
- **Antenna:** Built-in 3D antenna
- **SD Card:** microSD (up to 16GB)
- **Display:** 2.0" IPS LCD 320x240

## Connectivity

- **Wifi:** 802.11 b/g/n
- **Bluetooth:** Bluetooth 4.2, BLE

## Open Source

- **Firmware:** Yes
- **Schematics:** Yes
- **PCB Layout:** No

## Compatible Firmware

arduino, esp-idf, uiflow, micropython, platformio, esphome

## Use Cases

- iot-prototyping
- smart-home-dashboard
- stem-education
- environmental-monitoring
- sensor-node

## Components

- **ESP32-D0WDQ6-V3** (mcu): Espressif ESP32 SoC with dual-core Xtensa LX6 at 240MHz, WiFi 802.11 b/g/n and Bluetooth 4.2 + BLE — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.espressif.com%2Fsites%2Fdefault%2Ffiles%2Fdocumentation%2Fesp32_datasheet_en.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **ILI9342C** (display-driver): 320x240 IPS LCD driver with 853nit brightness, SPI interface — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fm5stack.oss-cn-shenzhen.aliyuncs.com%2Fresource%2Fdocs%2Fdatasheet%2Fcore%2FILI9342C-ILITEK.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **MPU6886** (accelerometer): TDK InvenSense 6-axis MEMS IMU with 3-axis gyroscope and 3-axis accelerometer, I2C interface — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Finvensense.tdk.com%2Fwp-content%2Fuploads%2F2021%2F12%2FDS-000451-MPU-6886-TYP-v1.3.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **BMM150** (magnetometer): Bosch 3-axis digital magnetometer for compass applications, I2C interface — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.bosch-sensortec.com%2Fmedia%2Fboschsensortec%2Fdownloads%2Fdatasheets%2Fbst-bmm150-ds001.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **IP5306** (battery-charger): Power management IC for LiPo battery charging and 5V boost output — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fm5stack.oss-cn-shenzhen.aliyuncs.com%2Fresource%2Fdocs%2Fdatasheet%2Fcore%2FIIC_IP5306_REG_V1.4.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **SK6812** (led-driver): 10 individually addressable RGB LEDs on M5GO base for status indication and light effects — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fcdn-shop.adafruit.com%2Fproduct-files%2F1138%2FSK6812%2BLED%2Bdatasheet%2B.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- **Analog MEMS Microphone** (microphone): Built-in analog MEMS microphone for voice input and sound detection — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fdocs.m5stack.com%2Fen%2Fcore%2Ffire_v2.7&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)

## Protocols

- **I2C**: SDA: GPIO21, SCL: GPIO22
- **SPI**: MOSI: GPIO23, MISO: GPIO19, CLK: GPIO18
- **UART**: TX: GPIO17, RX: GPIO16
- **DAC**: DAC1: GPIO25, DAC2: GPIO26

## GPIO Map

| Pin | Name | Type | Functions |
|-----|------|------|-----------|
| GPIO21 | I2C SDA / Grove Port A | I2C | digital-input, digital-output, pwm |
| GPIO22 | I2C SCL / Grove Port A | I2C | digital-input, digital-output, pwm |
| GPIO17 | UART TX / Grove Port C | UART | digital-input, digital-output, pwm |
| GPIO16 | UART RX / Grove Port C | UART | digital-input, digital-output, pwm |
| GPIO36 | ADC / Grove Port B | ADC | adc, input-only |
| GPIO26 | DAC / Grove Port B | DAC | digital-input, digital-output, dac, adc, pwm |
| GPIO25 | DAC1 / Speaker | DAC | digital-input, digital-output, dac, adc, pwm |
| GPIO35 | ADC Input | ADC | adc, input-only |
| GPIO34 | Microphone ADC | ADC | adc, input-only |
| GPIO19 | SPI MISO | SPI | digital-input, digital-output, pwm |

## Accessories

- m5go-charging-base

## Description

## Overview

The M5Stack FIRE V2.7 is a feature-rich ESP32-based IoT development kit that builds on M5Stack's modular stackable ecosystem. It packs a dual-core Xtensa LX6 processor running at 240MHz with 8MB PSRAM and 16MB flash into a compact 54mm square enclosure with a 2.0-inch IPS LCD display (320x240, 853nit brightness).

The FIRE edition differentiates itself from the Basic Core by including 8MB PSRAM for memory-intensive applications, a BMM150 3-axis magnetometer for compass functionality, 10 programmable SK6812 RGB LEDs on the M5GO base, and a larger 500mAh battery. The M5GO charging base adds LEGO-compatible connectors for mechanical integration and a dedicated charging dock.

The kit includes three programmable buttons, a built-in microphone, 1W speaker, microSD card slot, and three Grove expansion ports (I2C, UART, and analog/DAC) for connecting sensors and actuators. An extensive software ecosystem supports Arduino, ESP-IDF, UIFlow, MicroPython, ESPHome, and PlatformIO.

## Where to Buy

- [M5Stack Official](https://openhardware.directory/r?to=https%3A%2F%2Fshop.m5stack.com%2Fproducts%2Fm5stack-fire-iot-development-kit-psram-v2-7&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export) — $49.90

## Resources

- [product](https://openhardware.directory/r?to=https%3A%2F%2Fshop.m5stack.com%2Fproducts%2Fm5stack-fire-iot-development-kit-psram-v2-7&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- [github](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Fm5stack%2FM5Stack&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- [wiki](https://openhardware.directory/r?to=https%3A%2F%2Fdocs.m5stack.com%2Fen%2Fcore%2Ffire_v2.7&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- [datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fm5stack.oss-cn-shenzhen.aliyuncs.com%2Fresource%2Fdocs%2Fdatasheet%2Fcore%2Fesp32_datasheet_en.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)
- [schematics](https://openhardware.directory/r?to=https%3A%2F%2Fm5stack.oss-cn-shenzhen.aliyuncs.com%2Fresource%2Fdocs%2Fschematic%2FCore%2FM5-Core-Schematic%2820171206%29.pdf&ref=openhardware.directory&product=m5stack-fire-v2-7&source=md-export)

## Tags

`esp32`, `m5stack`, `psram`, `imu`, `magnetometer`, `rgb-led`, `lcd`, `iot`, `grove`

## Images

![M5Stack FIRE V2.7](https://nbg1.your-objectstorage.com/openhardware-directory/entities/m5stack-fire-v27/7b9918a331dc.webp)
![M5Stack FIRE V2.7](https://nbg1.your-objectstorage.com/openhardware-directory/entities/m5stack-fire-v27/c455e2c33176.webp)
![M5Stack FIRE V2.7](https://nbg1.your-objectstorage.com/openhardware-directory/entities/m5stack-fire-v27/2e4259b7a716.webp)
![M5Stack FIRE V2.7](https://nbg1.your-objectstorage.com/openhardware-directory/entities/m5stack-fire-v27/de2078fa24d0.webp)
![M5Stack FIRE V2.7](https://nbg1.your-objectstorage.com/openhardware-directory/entities/m5stack-fire-v27/49c0487854b6.webp)

> **Battery Powered:** LiPo 3.7V

---
