ACEBOTT QD001 Smart Robot Car
ESP32-powered 4WD mecanum wheel robot car kit with ultrasonic, IR, and line-tracking sensors. Programmable via Arduino, ACECode, and Python. Expandable with camera, AI, tank, robot arm, and GPS packs.
$83.95
Tap any value to browse matching devices
Specifications
Components
HC-SR04 ultrasonic ranging module for obstacle detection and distance measurement with 2cm-400cm range
Infrared receiver for IR remote control functionality, enabling wireless control via included remote
Infrared reflective sensors for line detection and following, supporting multiple route tracking patterns
Four DC gear motors paired with mecanum wheels enabling omnidirectional movement including lateral, diagonal, and rotational motion
Bus Interfaces
ACEBOTT QD001 Smart Robot Car
The ACEBOTT QD001 is an ESP32-based 4WD robot car kit featuring mecanum wheels for omnidirectional movement. Designed for ages 8-16, it serves as a STEM education platform with multiple sensors and extensive expansion options.
Key Features
- 4WD Mecanum Wheels: Multi-directional movement (forward, backward, sideways, diagonal, rotation)
- ESP32 Controller: Built-in WiFi and Bluetooth for wireless control
- Multiple Sensors: Ultrasonic (obstacle avoidance), IR (remote control), line-tracking (multiple route following)
- Multiple Control Methods: IR remote, web-based control, mobile app
- Extensive Expansion System: 10+ expansion packs available
Programming
Programmable through multiple environments:
- Arduino IDE (C/C++)
- ACECode (ACEBOTT's block-based IDE)
- Python
Expansion Packs
The modular design supports numerous expansion packs:
- Camera Pack
- AI Vision Expansion Pack
- Tank Treads Pack
- Shooting Pack
- Robot Arm Expansion Pack
- Solar Pack
- GPS Pack
Specifications
| Spec | Value |
|---|---|
| Controller | ESP32 |
| Drive | 4WD Mecanum Wheels |
| Sensors | Ultrasonic, IR, Line-tracking |
| Connectivity | WiFi, Bluetooth, IR |
| Programming | Arduino, ACECode, Python |
| Age Range | 8-16+ |
