# BigTreeTech SKR 3 EZ

> Advanced 32-bit 3D printer board with STM32H743VI @ 480MHz and EZ driver system (tool-free). 5 EZ driver slots, CAN/FDCAN, WiFi module support, 10A bed, 12–24V. Marlin, Klipper, RRF ready.

## Quick Facts

- **Brand:** BigTreeTech
- **Board Type:** 3D Printer Control Board
- **Price:** ~$44.99
- **Product Readiness:** consumer
- **CPU:** STM32H743VI
- **CPU Architecture:** ARM Cortex-M7
- **CPU Cores:** 1
- **RAM:** 1MB
- **Flash:** 2MB
- **USB:** USB Type-C
- **Power:** 12-24V DC
- **Operating Voltage:** 3.3V
- **SD Card:** MicroSD

## Connectivity

- **Wifi:** optional (ESP module)

## Open Source

- **Firmware:** Yes
- **Schematics:** Yes
- **PCB Layout:** Yes

## Compatible Firmware

Marlin, Klipper, RepRapFirmware

## Use Cases

- 3D Printing
- CNC
- Laser Engraving

## Components

- **STM32H743VI** (MCU): STMicroelectronics STM32H743VI 32-bit ARM Cortex-M7 microcontroller, 2MB flash, 1MB RAM, running at 480MHz with FDCAN bus support — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.st.com%2Fresource%2Fen%2Fdatasheet%2Fstm32h743vi.pdf&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)
- **BTT EZ Driver socket x5** (Stepper Driver Socket): 5x EZ driver sockets with 5V signal logic for tool-free, orientation-safe installation. Compatible with BTT EZ2209, EZ2208, EZ5160, EZ2130 drivers — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Fbigtreetech%2FSKR-3&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)
- **ESP32 (optional)** (Wireless Module): Optional WiFi connectivity via ESP-12S, ESP-07S, ESP32U, or ESP32E module for OctoPrint/Mainsail wireless access — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.espressif.com%2Fsites%2Fdefault%2Ffiles%2Fdocumentation%2Fesp32_datasheet_en.pdf&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)
- **MicroSD slot** (Storage): MicroSD card slot for firmware and print file storage — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fbiqu.equipment%2Fproducts%2Fbigtreetech-btt-skr-3-ez-control-board-mainboard-for-3d-printer&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)

## Protocols

- **UART**
- **SPI**
- **I2C**
- **USB**
- **CAN bus**
- **FDCAN**

## Description

The BigTreeTech SKR 3 EZ is a variant of the SKR 3 that introduces the EZ driver system — a simplified tool-free stepper driver socket with 5V logic signaling that eliminates orientation errors and simplifies installation. It shares the same powerful STM32H743VI ARM Cortex-M7 processor at 480MHz and FDCAN bus as the standard SKR 3.

The EZ driver system uses 5V logic level for stepper driver signal pins (vs 3.3V on SKR 3), making it compatible with the BTT EZ2209, EZ2208, EZ5160, EZ2130, and other EZ-series drivers. The thermistor pull-up resistor uses 2.2KΩ (vs 1KΩ on SKR 3), providing improved PT1000 temperature sensor accuracy at the same ADC resolution. All other hardware specifications are identical to the SKR 3.

Features include 5 EZ driver slots, 10A heated bed output, dual hotend outputs, 3 selectable-voltage CNC fan ports, WiFi via optional ESP module, CAN/FDCAN expansion, BLTouch, filament detection, RGB LEDs, and MicroSD storage. Input is 12–24V DC. Full open-source hardware is available on GitHub alongside firmware builds for Marlin, Klipper, and RepRapFirmware.

## Where to Buy

- [BIQU Equipment](https://openhardware.directory/r?to=https%3A%2F%2Fbiqu.equipment%2Fproducts%2Fbigtreetech-btt-skr-3-ez-control-board-mainboard-for-3d-printer&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export) — $44.99

## Resources

- [github](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Fbigtreetech%2FSKR-3&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)
- [product](https://openhardware.directory/r?to=https%3A%2F%2Fbiqu.equipment%2Fproducts%2Fbigtreetech-btt-skr-3-ez-control-board-mainboard-for-3d-printer&ref=openhardware.directory&product=bigtreetech-skr-3-ez&source=md-export)

## Tags

`3d-printer`, `control-board`, `stm32h7`, `marlin`, `klipper`, `reprapfirmware`, `bigtreetech`, `open-source`, `32-bit`, `ez-driver`, `can-bus`, `fdcan`, `wifi`, `tool-free`
