# CompuLab IOT-GATE-IMX8PLUS

> Industrial IoT edge gateway with NXP i.MX8M Plus quad-core Cortex-A53 at 1.8GHz, up to 8GB RAM, dual Ethernet (PoE), WiFi/BT, optional 4G LTE, 3x RS485/RS232, USB 3.0, TPM, and modular I/O expansion — designed for industrial-grade edge computing.

## Quick Facts

- **Brand:** CompuLab
- **Board Type:** IoT Controller
- **Price:** ~$495
- **Product Readiness:** consumer
- **CPU:** ARM Cortex-A53 4x1.8GHz, NXP i.MX8M Plus, 2 TOPS NPU
- **CPU Architecture:** ARM Cortex-A53
- **CPU Cores:** 4
- **RAM:** 2GB/4GB/8GB LPDDR4
- **Flash:** 16GB/32GB/128GB eMMC
- **USB:** USB 3.0,2x USB 2.0
- **Power:** 12V DC or PoE
- **Operating Voltage:** 3.3V
- **Operating Temp:** -30°C to 70°C
- **Antenna:** External antenna connectors
- **SD Card:** No

## Connectivity

- **Wifi:** 802.11ac
- **Bluetooth:** Bluetooth 5.0
- **Ethernet:** 2x Gigabit (1x PoE)
- **Cellular:** 4G LTE (optional)

## Open Source

- **Firmware:** No
- **Schematics:** No
- **PCB Layout:** No

## Certifications

CE, FCC

## Compatible Firmware

arduino

## Use Cases

- industrial-automation
- iot-gateway
- industrial-iot

## Components

- **i.MX8M-Plus** (mcu): NXP i.MX8M Plus quad-core ARM Cortex-A53 at 1.8GHz with 2 TOPS NPU, dual camera ISP, and hardware crypto. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.nxp.com%2Fdocs%2Fen%2Fdata-sheet%2FIMX8MPLUSCEC.pdf&ref=openhardware.directory&product=compulab-iot-gate-imx8plus&source=md-export)

## Protocols

- **RS485**: notes: Up to 3x RS485 ports
- **RS232**: notes: Up to 3x RS232 ports
- **Ethernet**: notes: 2x RJ45 Gigabit
- **I2C**: notes: Via expansion

## GPIO Map

| Pin | Name | Type | Functions |
|-----|------|------|-----------|
| DI1 | Digital Input |  | digital-input |
| DI2 | Digital Input |  | digital-input |
| DO1 | Digital Output |  | digital-output |
| DO2 | Digital Output |  | digital-output |

## Description

## Overview

The CompuLab IOT-GATE-IMX8PLUS is a modular industrial IoT edge gateway built around the NXP i.MX8M Plus quad-core Cortex-A53 at 1.8GHz with up to 8GB LPDDR4 RAM and up to 128GB eMMC storage. Designed for demanding industrial environments, it combines compute power with extensive I/O in a rugged enclosure.

Connectivity includes dual Gigabit Ethernet (one with optional PoE 802.3af), WiFi 802.11ac with Bluetooth 5.0, and optional 4G LTE modem with global band support. Industrial I/O features up to 3x RS485/RS232 serial ports, digital I/O, USB 3.0 and USB 2.0 host ports, and a mini-PCIe socket for additional expansion.

The integrated 2 TOPS NPU enables on-device AI inference, while TPM 2.0 provides hardware-based security. Running Yocto Linux or Debian with Docker, Azure IoT, Node-RED, and Mender OTA support, the IOT-GATE-IMX8PLUS targets factory automation, building management, energy monitoring, and smart city infrastructure. CompuLab backs it with a 5-year warranty and 15-year availability commitment.
