# BigTreeTech Panda PWR

> Intelligent power management module with ESP8684 MCU, 4MB flash, 2.4GHz WiFi, and dual USB outputs. Enables remote power control, consumption monitoring, countdown shutdown, and Home Assistant integration.

## Quick Facts

- **Brand:** BigTreeTech
- **Board Type:** power-module
- **Price:** ~$38.99
- **Product Readiness:** consumer
- **CPU:** ESP8684-MINI-1-H4
- **CPU Architecture:** RISC-V 32-bit single-core
- **CPU Cores:** 1
- **RAM:** 272KB
- **Flash:** 4MB
- **USB:** USB-A (×2 output),USB Type-C (firmware/input)
- **Power:** 220VAC mains input; 5V USB output
- **Operating Voltage:** 3.3V
- **Operating Temp:** -10°C to 60°C
- **SD Card:** No

## Connectivity

- **Wifi:** 802.11 b/g/n 2.4GHz

## Open Source

- **Firmware:** Yes
- **Schematics:** Yes
- **PCB Layout:** Yes

## Compatible Firmware

Home Assistant

## Use Cases

- 3d-printer
- smart-home
- power-management
- remote-control

## Components

- **ESP8684 WiFi SoC** (wireless): Espressif ESP8684 single-core RISC-V SoC with integrated 2.4GHz WiFi for remote power control and monitoring — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fwww.espressif.com%2Fsites%2Fdefault%2Ffiles%2Fdocumentation%2Fesp8684_datasheet_en.pdf&ref=openhardware.directory&product=bigtreetech-panda-pwr&source=md-export)
- **Mains Power Relay** (relay): High-voltage relay for switching 220VAC mains power to the connected printer — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Fbigtreetech%2FPandaPWR&ref=openhardware.directory&product=bigtreetech-panda-pwr&source=md-export)

## Protocols

- **WiFi 802.11 b/g/n**
- **MQTT**
- **HTTP REST API**
- **USB 2.0**

## Description

The BigTreeTech Panda PWR is a smart power management module built around the ESP8684-MINI-1-H4 MCU (RISC-V single-core, 272KB RAM, 4MB flash). It provides intelligent control over 3D printer power, with features including remote on/off via LAN web UI, power consumption monitoring, countdown auto-shutdown, and OTA firmware updates.

The module has two USB output ports: USB1 tracks the printer's running state for synchronized accessory control (e.g., lights follow printer status), while USB2 provides continuous 5V power delivery. It can operate standalone or in conjunction with the Panda Touch display for a seamless smart-printer experience. A Home Assistant community integration is also available for smart home automation.

The Panda PWR connects inline with mains power (220VAC input) for full printer power control, making it practical for automated shutdown after print completion to save energy and prevent fire risk. Full API documentation and firmware source are available in the GitHub repository.

## Where to Buy

- [BIQU Equipment](https://openhardware.directory/r?to=https%3A%2F%2Fbiqu.equipment%2Fproducts%2Fbigtreetech-panda-pwr-intelligent-power-management-module&ref=openhardware.directory&product=bigtreetech-panda-pwr&source=md-export) — $38.99

## Resources

- [github](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Fbigtreetech%2FPandaPWR&ref=openhardware.directory&product=bigtreetech-panda-pwr&source=md-export)
- [product](https://openhardware.directory/r?to=https%3A%2F%2Fbiqu.equipment%2Fproducts%2Fbigtreetech-panda-pwr-intelligent-power-management-module&ref=openhardware.directory&product=bigtreetech-panda-pwr&source=md-export)

## Tags

`power-management`, `smart-plug`, `wifi`, `mqtt`, `home-assistant`, `3d-printer`, `bigtreetech`, `open-source`, `panda-series`, `esp8684`
