# Arduino Nano Every > Compact 45×18mm Arduino Nano with ATMega4809 at 20MHz — 48KB flash, 6KB SRAM, 5V logic, 14 digital I/O (5 PWM), 8 analog inputs, and USB-C. A modern, affordable 8-bit board for embedded projects and breadboard prototyping. ## Quick Facts - **Brand:** Arduino - **Board Type:** dev-board - **Price:** ~$10.5 - **Product Readiness:** consumer - **CPU:** ATMega4809 @ 20MHz, 8-bit AVR - **CPU Architecture:** AVR - **CPU Cores:** 1 - **RAM:** 6KB SRAM - **Flash:** 48KB - **USB:** Micro-USB - **Power:** 5V via Micro-USB or Vin - **Operating Voltage:** 5V - **Dimensions:** 45 × 18mm - **Weight:** 5g - **Antenna:** No - **SD Card:** No ## Open Source - **Firmware:** Yes - **Schematics:** Yes - **PCB Layout:** No ## Compatible Firmware arduino ## Use Cases - educational-platform - iot ## Components - **ATMega4809** (mcu): Microchip ATMega4809 at 20MHz with 48KB flash, 6KB SRAM, and improved analog peripherals over ATmega328P. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fww1.microchip.com%2Fdownloads%2Fen%2FDeviceDoc%2FATmega4808-4809-Data-Sheet-DS40002173A.pdf&ref=openhardware.directory&product=arduino-nano-every&source=md-export) ## Protocols - **SPI**: MOSI: D11, MISO: D12, SCK: D13, SS: D10 - **I2C**: SDA: A4, SCL: A5 - **UART**: TX: D1, RX: D0 ## GPIO Map | Pin | Name | Type | Functions | |-----|------|------|-----------| | D0 | UART RX | UART | digital-input, digital-output | | D1 | UART TX | UART | digital-input, digital-output | | D2 | Digital I/O | | digital-input, digital-output | | D3 | PWM | PWM | digital-input, digital-output, pwm | | D4 | Digital I/O | | digital-input, digital-output | | D5 | PWM | PWM | digital-input, digital-output, pwm | | D6 | PWM | PWM | digital-input, digital-output, pwm | | D7 | Digital I/O | | digital-input, digital-output | | D8 | Digital I/O | | digital-input, digital-output | | D9 | PWM | PWM | digital-input, digital-output, pwm | | D10 | PWM / SPI SS | SPI | digital-input, digital-output, pwm | | D11 | SPI MOSI | SPI | digital-input, digital-output | | D12 | SPI MISO | SPI | digital-input, digital-output | | D13 | SPI SCK / LED | SPI | digital-input, digital-output | | A0 | Analog Input | ADC | digital-input, digital-output, adc | | A1 | Analog Input | ADC | digital-input, digital-output, adc | | A2 | Analog Input | ADC | digital-input, digital-output, adc | | A3 | Analog Input | ADC | digital-input, digital-output, adc | | A4 | I2C SDA / Analog | I2C | digital-input, digital-output, adc | | A5 | I2C SCL / Analog | I2C | digital-input, digital-output, adc | | A6 | Analog Input | ADC | adc | | A7 | Analog Input | ADC | adc | ## Description ## Overview The Arduino Nano Every is a compact, affordable microcontroller board that brings modern improvements to the classic Nano form factor. Powered by the ATMega4809 running at 20MHz, it offers 48KB flash (50% more than the UNO) and 6KB SRAM (200% more), making it a significant step up from ATmega328P-based boards while maintaining 5V compatibility. At just 45×18mm, the Nano Every fits directly into breadboards and features 14 digital I/O pins (5 with PWM), 8 analog inputs, SPI, I2C, and UART interfaces. It connects via Micro USB and is available with or without pre-soldered headers, making it suitable for both prototyping and direct PCB integration. The board is ideal for space-constrained projects, wearables, robotics, and educational use where WiFi connectivity isn't needed but compact size and 5V operation are essential. ## Where to Buy - [Arduino Store (US)](https://openhardware.directory/r?to=https%3A%2F%2Fstore-usa.arduino.cc%2Fproducts%2Fnano-every&ref=openhardware.directory&product=arduino-nano-every&source=md-export) — $10.50 - [Arduino Store (EU)](https://openhardware.directory/r?to=https%3A%2F%2Fstore.arduino.cc%2Fproducts%2Fnano-every&ref=openhardware.directory&product=arduino-nano-every&source=md-export) — €11.61 - [DigiKey](https://openhardware.directory/r?to=https%3A%2F%2Fwww.digikey.com%2Fen%2Fproducts%2Fdetail%2Farduino%2FABX00028%2F10238801&ref=openhardware.directory&product=arduino-nano-every&source=md-export) — $13.80 - [Mouser](https://openhardware.directory/r?to=https%3A%2F%2Fwww.mouser.com%2FProductDetail%2FArduino%2FABX00028&ref=openhardware.directory&product=arduino-nano-every&source=md-export) — $13.80 - [Amazon US](https://openhardware.directory/r?to=https%3A%2F%2Fwww.amazon.com%2Fdp%2FB07VX7MX27&ref=openhardware.directory&product=arduino-nano-every&source=md-export) — $14.00 ## Resources - [product](https://openhardware.directory/r?to=https%3A%2F%2Fstore.arduino.cc%2Fproducts%2Fnano-every&ref=openhardware.directory&product=arduino-nano-every&source=md-export) - [wiki](https://openhardware.directory/r?to=https%3A%2F%2Fdocs.arduino.cc%2Fhardware%2Fnano-every%2F&ref=openhardware.directory&product=arduino-nano-every&source=md-export) - [datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fdocs.arduino.cc%2Fresources%2Fdatasheets%2FABX00028-datasheet.pdf&ref=openhardware.directory&product=arduino-nano-every&source=md-export) - [schematics](https://openhardware.directory/r?to=https%3A%2F%2Fdocs.arduino.cc%2Fresources%2Fschematics%2FABX00028-schematics.pdf&ref=openhardware.directory&product=arduino-nano-every&source=md-export) ## Tags `arduino`, `nano`, `atmega4809`, `5v`, `breadboard`, `compact` ## Images ![Arduino Nano Every](https://nbg1.your-objectstorage.com/openhardware-directory/entities/arduino-nano-every/691a9711f0e9.jpg) ![Arduino Nano Every](https://nbg1.your-objectstorage.com/openhardware-directory/entities/arduino-nano-every/24902aae2116.jpg) --- [View full device page](https://openhardware.directory/devices/arduino-nano-every)
