# LuckFox PicoKVM

> Compact IP-KVM remote management tool based on RV1106G3, capturing 1080p@60fps HDMI with H.264 encoding at 80-200ms latency. Features 100M Ethernet, USB HID/UMS emulation, Wake-on-LAN, web terminal, and optional 1.54-inch touch display.

## Quick Facts

- **Brand:** LuckFox
- **Board Type:** KVM Device
- **Price:** ~$44.99
- **CPU:** ARM Cortex-A7 @ 1.2GHz + RISC-V MCU, 1 TOPS NPU
- **CPU Architecture:** ARM Cortex-A7
- **CPU Cores:** 1
- **RAM:** 256MB DDR3
- **Flash:** 8GB eMMC
- **USB:** USB-C (power/HID/UMS)
- **Power:** 5V
- **Operating Voltage:** 3.3V
- **Dimensions:** 48.5 × 48.5 × 29mm (full version)
- **SD Card:** microSD
- **Display:** 1.54" IPS LCD 240x240

## Connectivity

- **Ethernet:** 10/100 Mbps

## Use Cases

- kvm-over-usb
- headless-server-management

## Components

- **RV1106** (soc): Rockchip RV1106G3 SoC handling HDMI video capture, H.264 encoding at 1080p@60fps, and USB HID/UMS device emulation for KVM functionality. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Frockchips.net%2Fwp-content%2Fuploads%2F2025%2F03%2FRockchip-RV1106-Datasheet-V1.7-20231218.pdf&ref=openhardware.directory&product=waveshare-luckfox-picokvm&source=md-export)

## Description

## Overview

The LuckFox PicoKVM is a lightweight IP-KVM (keyboard, video, mouse over IP) remote management tool powered by the Rockchip RV1106G3 SoC. It captures HDMI video input at up to 1920x1080@60fps with H.264 encoding and streams it over 100Mbps Ethernet with 80-200ms latency, enabling remote BIOS/UEFI-level access to headless servers and workstations without requiring any software installation on the target machine.

The device simulates USB keyboard and mouse input via HID emulation and supports USB mass storage (UMS) emulation for mounting virtual drives, making it possible to remotely install operating systems or boot recovery tools. Additional features include Wake-on-LAN (WOL) for remote power-on, a web-based terminal interface, serial console access (1 channel), and custom script support for automation.

The full version includes a 1.54-inch 240x240 touchscreen display and a compact enclosure measuring just 48.5 x 48.5 x 29mm. With 256MB DDR3 RAM and 8GB eMMC storage, plus a TF card slot for expansion, the PicoKVM provides a cost-effective alternative to enterprise KVM-over-IP solutions for homelab administrators and data center operators who need out-of-band management capabilities.

## Where to Buy

- [Waveshare](https://openhardware.directory/r?to=https%3A%2F%2Fwww.waveshare.com%2Fproduct%2Fluckfox%2Fboards-modules%2Fluckfox-picokvm.htm&ref=openhardware.directory&product=waveshare-luckfox-picokvm&source=md-export) — 44.99

## Resources

- [product](https://openhardware.directory/r?to=https%3A%2F%2Fwww.waveshare.com%2Fproduct%2Fluckfox%2Fboards-modules%2Fluckfox-picokvm.htm&ref=openhardware.directory&product=waveshare-luckfox-picokvm&source=md-export)
- [wiki](https://openhardware.directory/r?to=https%3A%2F%2Fwiki.luckfox.com%2FLuckfox-PicoKVM&ref=openhardware.directory&product=waveshare-luckfox-picokvm&source=md-export)
- [datasheet](https://openhardware.directory/r?to=https%3A%2F%2Frockchips.net%2Fwp-content%2Fuploads%2F2025%2F03%2FRockchip-RV1106-Datasheet-V1.7-20231218.pdf&ref=openhardware.directory&product=waveshare-luckfox-picokvm&source=md-export)
