# NanoPi R4S

> Popular RK3399 dual-GbE router board with 2x Cortex-A72 + 4x Cortex-A53, 4GB LPDDR4, dual Gigabit Ethernet, 2x USB 3.0, metal case option, and OpenWrt/FriendlyWrt support — the go-to affordable open-source router platform.

## Quick Facts

- **Brand:** FriendlyElec
- **Board Type:** sbc
- **Price:** ~$55
- **Product Readiness:** consumer
- **CPU:** ARM Cortex-A72 2x2.0GHz,Cortex-A53 4x1.5GHz, RK3399
- **CPU Architecture:** ARM Cortex-A72
- **CPU Cores:** 6
- **RAM:** 4GB LPDDR4
- **Flash:** none (microSD boot)
- **USB:** 2x USB 3.0 Type-A,USB-C (power)
- **Power:** 5V/3A via USB-C
- **Operating Voltage:** 3.3V
- **Operating Temp:** -20°C to 70°C
- **Dimensions:** 66 × 66mm
- **Weight:** 41g
- **Antenna:** No
- **SD Card:** microSD (up to 128GB)

## Connectivity

- **Ethernet:** 2x Gigabit

## Open Source

- **Firmware:** Yes
- **Schematics:** Yes
- **PCB Layout:** No

## Compatible Firmware

arduino

## Use Cases

- iot-gateway
- wired-networking
- iot

## Components

- **RK3399** (mcu): Rockchip RK3399 with 2x Cortex-A72 at 2.0GHz + 4x Cortex-A53 at 1.5GHz, Mali-T864 GPU, 4K video. — [Datasheet](https://openhardware.directory/r?to=https%3A%2F%2Fopensource.rock-chips.com%2Fimages%2F6%2F60%2FRockchip_RK3399_Datasheet_V2.1-20200323.pdf&ref=openhardware.directory&product=nanopi-r4s&source=md-export)

## Protocols

- **I2C**: notes: Via 10-pin GPIO header
- **SPI**: notes: Via 10-pin GPIO header
- **UART**: notes: Debug UART 3-pin header

## GPIO Map

| Pin | Name | Type | Functions |
|-----|------|------|-----------|
| GPIO1 | I2C SDA | I2C | digital-input, digital-output |
| GPIO2 | I2C SCL | I2C | digital-input, digital-output |
| GPIO3 | SPI CLK | SPI | digital-input, digital-output |
| GPIO4 | SPI MOSI | SPI | digital-input, digital-output |

## Description

## Overview

The NanoPi R4S is one of the most popular open-source router boards, built around the proven Rockchip RK3399 with dual Cortex-A72 cores at 2.0GHz and quad Cortex-A53 cores at 1.5GHz. With 4GB LPDDR4 RAM and dual Gigabit Ethernet ports (one native, one PCIe), it delivers excellent routing and firewall throughput.

Two USB 3.0 Type-A ports enable NAS functionality with external drives, while the compact 66×66mm form factor with optional metal case makes it deployable anywhere. A 10-pin GPIO header provides I2C and SPI for sensor expansion.

Running FriendlyWrt (OpenWrt) out of the box, it's widely used as a home router, VPN gateway, Pi-hole ad blocker, and network monitoring appliance. The large community and extensive OpenWrt package ecosystem make it one of the most versatile network appliance platforms available at its price point.

## Where to Buy

- [FriendlyElec](https://openhardware.directory/r?to=https%3A%2F%2Fwww.friendlyelec.com%2Findex.php%3Froute%3Dproduct%2Fproduct%26product_id%3D284&ref=openhardware.directory&product=nanopi-r4s&source=md-export) — $55.00
- [Amazon US](https://openhardware.directory/r?to=https%3A%2F%2Fwww.amazon.com%2Fdp%2FB09FH22SGP&ref=openhardware.directory&product=nanopi-r4s&source=md-export) — $65.00

## Resources

- [product](https://openhardware.directory/r?to=https%3A%2F%2Fwww.friendlyelec.com%2Findex.php%3Froute%3Dproduct%2Fproduct%26product_id%3D284&ref=openhardware.directory&product=nanopi-r4s&source=md-export)
- [wiki](https://openhardware.directory/r?to=https%3A%2F%2Fwiki.friendlyelec.com%2Fwiki%2Findex.php%2FNanoPi_R4S&ref=openhardware.directory&product=nanopi-r4s&source=md-export)
- [github](https://openhardware.directory/r?to=https%3A%2F%2Fgithub.com%2Ffriendlyarm%2Fsd-fuse_rk3399&ref=openhardware.directory&product=nanopi-r4s&source=md-export)

## Tags

`friendlyelec`, `nanopi`, `rk3399`, `router`, `openwrt`, `dual-gbe`

## Images

![NanoPi R4S](https://nbg1.your-objectstorage.com/openhardware-directory/entities/nanopi-r4s/406b68391152.jpg)

---
